25m Heavy Duty Warehouse Racking 1500kg Load Steel Shuttle Racking

Name: 25m Heavy Duty Warehouse Racking 1500kg Load Steel Shuttle Racking
Brand: Jiangsu Union Logistics System Engineering Co., Ltd.
SKU: UNSR-6
Availability: InStock

Product Details

Place of Origin: Nanjing, China

Brand Name: Union

Certification: CE, ISO9001

Model Number: UNSR-6

Payment & Shipping Terms

Minimum Order Quantity: 1*20GP

Price: Negotiable

Packaging Details: wrap film packaging

Delivery Time: from the 15th working day after we receive the deposit

Payment Terms: L/C, T/T

Supply Ability: 2000T per month

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                25m Heavy Duty Warehouse Racking, Heavy Duty Warehouse Racking 1500kg, 1500kg Load Steel Shuttle Racking


Material:	Steel	Size:	Customized
Color:	Blue And Orange	Feature:	Corrosion Protection
Type:	Pallet Shuttle Rack	Weight Capacity:	500-4500KG
HS Code:	730890

Material:	Steel
Size:	Customized
Color:	Blue And Orange
Feature:	Corrosion Protection
Type:	Pallet Shuttle Rack
Weight Capacity:	500-4500KG
HS Code:	730890

Product Description

25m Heavy Duty Warehouse Racking 1500kg Load Steel Shuttle Racking

Product Specifications

Attribute	Value
Material	Steel
Size	Customized
Color	Blue and Orange
Feature	Corrosion Protection
Type	Pallet Shuttle Rack
Weight capacity	500-4500KG
HS Code	730890

25m Steel Warehouse Shelving Racks Shuttle Racking System for Pallet Storage

Shuttle racking, also known as pallet shuttle systems, is an advanced and highly efficient storage solution used in modern warehouses and distribution centers. This system combines the benefits of dense storage with improved selectivity and speed of operation.

Key Advantages of Radio Shuttle Racking

Automated System: Reduces the likelihood of human error and the potential for accidents.
Durability: Built to withstand the demands of continuous operation and heavy loads.

Product Features

Remote Control

Charging cabinets and battery

Shuttle car

Shuttle Carrier and Pallet Runner System

A compact storage system in which a shuttle driven by an electric motor runs on rails inside the storage channels, replacing forklifts, considerably reducing operating times and enabling items to be grouped by channels rather than complete lanes.

System Benefits

Space Saving: Increased number of pallets in depth: storage channels can exceed 40 in height; the limit is imposed by the handling means used.
Time Saving: Loading and unloading times are reduced, since the operator does not need to work inside the lanes. Movement speed of the shuttle of 90 in/min when empty, or 45 m/min when loaded. Load lifting cycle of just 2 seconds.
Cost Saving: The result of the benefits mentioned previously, together with the consumption of energy, is a reduction in costs, making Pallet Shuttle one of the most cost-effective compact storage systems.

Shuttle Car Technical Specifications

Item	Type	Specification
1.	Size range available(mm)	W1100-1250,D800-1100
2.	Deflection of pallet	Max.20mm
3.	Total weight of loading	Max 1500kg
4.	Running without loading	1.1m/s
5.	Running with max loading	0.5-0.9m/s
6.	Duration of charging	About 3 hours
7.	Methods of Remote control	Radio Frequency 433MHz/3.7V 1500AH
8.	Remote controller	Handheld remote control
9.	Programmable logic controller	Siemens PLC
10.	Integrated Performance	Integratable with WMS, WCS and vehicle dispatch system

Certifications

Trade Exhibitions

Frequently Asked Questions

What is your warranty?

2 year guarantee for free accessories and 10 years for the rack will not fall.

How to purchase your product?

Design drawing → Confirm drawing → Quotation → PI → Arrange 30% deposit → Manufacture → QC → Pay balance → Shipping

What's your advantage?

Factory price: factory direct sale competitive price.
Warranty: Two years warranty, the broken parts will be replaced and sent to you.
