High Density Pallet Shuttle System 2T Radio Shuttle Pallet Racking

Name: High Density Pallet Shuttle System 2T Radio Shuttle Pallet Racking
Brand: Jiangsu Union Logistics System Engineering Co., Ltd.
SKU: UNSR-3
Availability: InStock

Product Details

Place of Origin: Nanjing, China

Brand Name: Union

Certification: CE, ISO9001

Model Number: UNSR-3

Payment & Shipping Terms

Minimum Order Quantity: 1*20GP

Price: Negotiable

Packaging Details: wrap film packaging

Delivery Time: from the 15th working day after we receive the deposit

Payment Terms: L/C, T/T

Supply Ability: 2000T per month

Get Best Price

Product Details

Product Description

Product Details

Highlight:
                                                                                                                                                                                                                                                                                High Density Pallet Shuttle System, High Density Radio Shuttle Pallet Racking, 2T Radio Shuttle Pallet Racking


Material:	Steel	Size:	Customized
Color:	Blue And Orange	Feature:	Corrosion Protection
Type:	Pallet Shuttle Rack	Weight Capacity:	500-4500KG
HS Code:	730890

Material:	Steel
Size:	Customized
Color:	Blue And Orange
Feature:	Corrosion Protection
Type:	Pallet Shuttle Rack
Weight Capacity:	500-4500KG
HS Code:	730890

Product Description

High Density Pallet Shuttle System 2T Radio Shuttle Pallet Racking

Product Specifications

Attribute	Value
Material	Steel
Size	Customized
Color	Blue and Orange
Feature	Corrosion Protection
Type	Pallet Shuttle Rack
Weight capacity	500-4500KG
HS Code	730890

Product Description

High Density Industrial Automatic Steel Heavy Duty Radio Shuttle Rack

A radio shuttle pallet rack is a high-density storage solution that utilizes a radio-controlled shuttle device to handle pallet movement within racking structures. This system maximizes storage capacity and improves operational efficiency in warehouses and distribution centers.

Key Advantages of Radio Shuttle Racking

Maximizes storage density and warehouse space utilization
Improves operational efficiency with automated pallet handling
Reduces labor costs and forklift traffic in storage lanes
Enables first-in-first-out (FIFO) or last-in-first-out (LIFO) inventory management

Product Components

Remote Control

Charging cabinets and battery

Shuttle car

Shuttle Carrier System Features

The electric motor-driven shuttle runs on rails inside storage channels, replacing forklifts and significantly reducing operating times. This compact system enables items to be grouped by channels rather than complete lanes.

Operational Benefits

Space Saving: Storage channels can exceed 40 pallets in depth, limited only by handling equipment
Time Saving: Loading/unloading times reduced with 90 in/min shuttle speed (empty) and 45 in/min (loaded)
Cost Saving: Reduced energy consumption and labor requirements make this one of the most cost-effective compact storage systems

Shuttle Car Technical Specifications

Item	Type	Specification
1.	Size range available(mm)	W1100-1250,D800-1100
2.	Deflection of pallet	Max.20mm
3.	Total weight of loading	Max 1500kg
4.	Running without loading	1.1m/s
5.	Running with max loading	0.5-0.9m/s
6.	Duration of charging	About 3 hours
7.	Methods of Remote control	Radio Frequency 433MHz/3.7V 1500AH
8.	Remote controller	Handheld remote control
9.	Programmable logic controller	Siemens PLC
10.	Integrated Performance	Integratable with WMS, WCS and vehicle dispatch system

Quality Certification

Trade Exhibitions

Frequently Asked Questions

What is your warranty?

2 year guarantee for free accessories and 10 years structural warranty for the rack.

What is your purchasing process?

Design drawing → Confirm drawing → Quotation → PI → Arrange 30% deposit → Manufacture → QC → Pay balance → Shipping

What are your advantages?

Factory direct pricing with competitive rates
Two-year warranty with replacement parts shipped to you
Customized solutions for optimal warehouse space utilization
